The cabinet of the TIDAL Agoria is made out of TIDAL's proprietary cabinet material TIRALIT. This cabinet material does combines the rigidity of hard materials such as metal with the resonance absorbing behavior of softer materials such as wooden materials like MDF. While TIRADUR is 30mm thick, TIRALIT goes even further and is 42mm thick and combines more single layers. The materials itself, the process of making it and how the material reacts when it is getting excited by vibrations and resonances - all this we putted into consideration when we designed it.
It is the only advanced cabinet material allowing to use organic surfaces such as our famous polished veneers, as well as true polyester piano lacquer. So when you see the Agoria in our most beautiful veneers or our shiny black piano finish - don't make the mistake to think the cabinet is out of wooden materials or MDF.
BCC MIDRANGE WOOFERS
TIDAL's exclusive BCC driver technology is the result of the Accuton TIDAL cooperation for more than a decade and are to find only in TIDAL speakers. The diaphragm itself is a special coated black ceramic diaphragm and uses a "short coil / long gap" neodymium motor perfectly designed for the hermetically sealed and asymmetrical designed midrange chamber of the Contriva.
Embedded in a special shaped ring out of hand polished massive stainless steel to avoid reflections form the protection grill, needless to say that this driver does guarantee absolutely no compromise for the performance and reliability.
The TIDAL Agoria is designed to be adapted for the deep bass response with our unique Variobass technology, both passive or active to play perfect at any room. The unique passive radiators are mounted in impulse compensated configuration and support a very deep and low distortion reproduction of bass frequencies without any noise. We excite the bass modes very even within the room with all together 10 sources (4 subwoofers, 6 passive radiators), therefore the beast reproduction as far less critical like with other designs.
Here as well our polished stainless steel rings are not only our famous detail and does reflect our love to details, it is designed to clamp the drivers absolutely tight in to the TIRALIT cabinet.
The Agoria has a multiple adjustment Varioterminal. One can influence the bass and deep bass reproduction to almost every room in a so far unknown manner. More or less upper bass? More or less deep bass? More or less bass level? All is easy to do already in a complete passive mode. And talking about bass adjustment: the 3 sub-bass radiators can be tuned with several weights for best performance in the room as well.
The tweeter curve can be adjusted to hard, medium, soft or no reflections. Also the bass cross-over, as good as it is, can be all bypassed to drive it with our exclusive TIDAL LPX technology for practically endless flexibility and control then the subwoofers directly with the power amplifier.
- multi chamber cabinet made out of TIDAL's proprietary cabinet material TIRALIT™
- 1 x 30 mm (1,2") diamond tweeter (an exclusive Accuton TIDAL cooperation)
- 2 x 173 mm (7") BCC long excursion low distortion midrange woofers (an exclusive Accuton TIDAL cooperation)
- 2 x 280 mm (10,5") long excursion BCC subwoofers (an exclusive Accuton TIDAL cooperation
- 3 x 280 mm (10,5") long excursion BCC passive radiators (an exclusive Accuton TIDAL cooperation)
- passive crossover network with ultra low tolerance components, exclusive use of costume tailored CAST Duelund-copper-capacitors and CAST capacitors, metalfilm-resistors, silver-carbon resistors, air-core-inductors, ultra low resistance bass-inductor
- passive crossover is microphonic and hermetically isolated in a separated chambers
- total weight of the passive crossover construction: 19 Kg / 42 lbs.
- adjustable diamond-tweeter curve (hard room-refections / soft room-reflections / adjustable curve at 7KHz and 13KHz)
- adjustable upper bass curve
- Variobass, passive adjustable in three settings (linear, gain A and gain B)
- excellent low level listening reproduction
- pure silver binding posts for perfect contact, isolated massive aluminum knobs on fiberglass isolation core
- adjustable bi-wiring / passive bi-amping / active bi-amping double-terminal
- special microfibre-cleaning cloth for maintenance
- owners manual book with signature from the TIDAL employee who build the speakers
- special 5-part TIDAL stainless steel isolators
- optional: 8 x trigger bars out of massive aluminum, black structured or high gloss polished, the position of the variofeet can be mounted in parallel or sloped back, both on the frontside and/or backside
- serial cabinet finish: original TIDAL piano lacquer in midnight black
- optional cabinet finishes: finest hand selected veneers in TIDAL's original transparent piano lacquer.
- other finishes: on request
- the TIDAL Agoria is being delivered in 2 x ATA-flightcase, incl. all accessories inside
- nominal power handling: 200 / 1.000 VA
- nominal impedance: 4 Ohm
- recommended power amplifier: 30 watt and up. Very easy impedance load also for tube amps
- to use the whole enormous dynamic range of it and listening complex music also from time to time very loud we recommend > 200 watts at 4 ohm
- speaker dimensions: 163 cm x 31 cm x 60 cm / 64,2" high x 12,2" wide x 23,6" deep
- dimensions with vario feet (from ground to top): 170 cm high / 67" high
- speaker weight without packaging: 2 x 215 Kg / 2 x 475 lbs.
- shipping weight with packaging: 2 x 245 Kg / 2 x 540 lbs.
- shipping dimensions: 2 flightcases, each flight case is 182 cm length x 42 cm width x 72 cm height / 72" length x 16,5" width x 28" height
